Ortofon Concorde 5E – HiFi Cartridge | Moving Magnet

Concorde 5E – Precision & Clarity The Concorde 5E delivers a refined and detailed listening experience, making it an ideal choice for those who appreciate high-fidelity sound without unnecessary complexity. Equipped with an elliptical diamond stylus, it ensures premium groove contact, reduces distortion, and reveals fine nuances in your records. No-tool installation – easily mounts onto the tonearm for quick setup. Elliptical stylus – improves tracking and enhances detail in the music. Balanced and natural sound – perfect for music lovers seeking clarity and precision.

Concorde 5E – Precision & Clarity

The Concorde 5E delivers a refined and detailed listening experience, making it an ideal choice for those who appreciate high-fidelity sound without unnecessary complexity. Equipped with an elliptical diamond stylus, it ensures premium groove contact, reduces distortion, and reveals fine nuances in your records.

No-tool installation – easily mounts onto the tonearm for quick setup.
Elliptical stylus – improves tracking and enhances detail in the music.
Balanced and natural sound – perfect for music lovers seeking clarity and precision.

Product safety information

Manufacturer:

Contact: Email:

EU-Responsible Person:

Contact:

Cartridge specifications:

Model name: Concorde 5 E
Cartridge type: MM (Moving Magnet)
Output voltage: 4 mV
Cantilever material: Aluminium
Stylus grind: Elliptical Diamond
Radius of cartridge tip: r/R 8/18 µm
Stylus suspensions: Ortofon proprietary
Coil system: Quad coils
Coil wire: OFC
Channel balance at 1 kHz: < 2 dB
Channel separation at 1 kHz: > 22 dB
Frequency response 20 Hz - 20 kHz: +/- 3 dB
Stylus compliance: 20 µm/mN
Recommended tracking force: 1.8 grams
Recommended load resistance: 47 kΩ
Recommended load capacitance: 200-500 pF
Weight, cartridge: 18 grams
