Nagaoka

Nagaoka MP 300 H Cartridge incl. Headshell

Item-ID: 10206

* incl. VAT. plus shipping outside of Germany

The Nagaoka MP-300 phonograph cartridge offers sophistication, refinement and high-definition at all audible frequencies thus making it one of our favorite phonograph cartridges. It is nimble on the grooves and easy on the ears so you keep on wanting to listen. The Nagaoka MP300 is an advanced technology cartridge that is destined to become a classic out of the box.

Features
  • Exclusive super rigid body for ultra resonance and superb fidelity
  • Superfine polished special eliptical bonded diamond stylus
  • Powerfull samarium cobalt magnet
  • Hardened low-mass, high strenght boron cantilever
  • Carbon fibre reinforced plastic shoe
  • Anti ferro magnetic permalloy shield casing

  • Type: MI
  • Fixing: Half-inch mount
  • Output voltage: 3,0mV bei 1kHz, 5cm/sec.
  • Amplifier-connection: Phono MM
  • Frequency range: 20-25.000Hz
  • Material: diamond, nude
  • Stylus type: elliptical 0.4 x 0.7 mil
  • Tracking force range: 1,3-1,8g
  • Tracking force, recommended: 1,6g
  • Recommended load resistance: 47 kOhm
  • Recommended load capacitance: 150-200pF
  • Weight Cartridge: 8g
  • Weight Headshell: 13.5g
  • Dimensions: 18mm
